AC Current Transformer

Two versions available:

1) High-resolution (-HR) ≈1µArms wideband noise

• ±5mA up to ±2A full scale current range
• Output ±10V
• Dynamic range >1E4
• Bandwidth 3 Hz to 300 kHz (-3dB)
• Risetime (10%-90%) 1.2 us
• Output signal droop < 2 %/ms

2) Wideband (-WB) up to 1 MHz

• ±10mA up to ±2A full scale current range
• Output ±5V
• Bandwidth 3 Hz to 1 MHz (-3dB)
• Dynamic range >1E4
• Risetime (10%-90%) 350 ns
• Output signal droop < 2 %/ms

Three packaging types are available for the sensor :

• In-flange UHV installation in the beam line
• In-air installation over the vacuum chamber
• In-air installation with optional magnetic shield for high-resolution measurement in noisy environment
