The Analyzing Dipole pictured is a double focusing dipole magnet with R = 500 mm and maximum magnetic rigidity of 0.64 Tm. This corresponds to the rigidity of an ion of charge Q = 1, M = 50 accelerated to 25 kV. The Dipole can be mounted in a support stand of item 13. This dipole is standard and present excellent characteristics. It allows mass resolution of about 150 in the focal plane, where collimators can be placed for having good beam selection.
